Containerized electric generators
The RHINO line - output between 180 and 2,060 kVA - from 6 to 12 cylinders
DIESEL ELECTRIC GENERATORS IN CONTAINERS AND FITTED CONTAINERS.
Generators in containers are used as a backup, as a grid, or for production on the grid, are easily transported over land or sea, for maximum power.
Perfect for one time or ongoing needs, this solution allows you to install and use your containerized electric generator in record time.
LOW, MEDIUM AND HIGH TENSION APPLICATIONS
With its synchronization, coupling and charge sharing abilities, the RHINO line stands out from the others. These electric generators can be synchronized so that you can install electric power plants up to several megawatts.
A SOLUTION YOU CAN USE RIGHT AWAY
The container concept allows you to quickly have a complete “all in one” solution that is climate and burglar proof.
The heavy Line
From 176 to 2,060 kVA
RHINO-180YC - 178 KVA
178 kVA GENERATOR
- ESP Power : 178 kVA
- PRP Power : 162,5 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (234,8 A)
- Type of container : 20′ HC
RHINO-200YC - 198 KVA
198 kVA GENERATOR
- ESP Power : 198 kVA
- PRP Power : 180 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (260,1 A)
- Type of container : 20′ HC
RHINO-250YC - 247 KVA
247 kVA GENERATOR
- ESP Power : 247 kVA
- PRP Power : 225 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (326 A)
- Type of container : 20′ HC
RHINO-280YC - 275 KVA
275 kVA GENERATOR
- ESP Power : 275 kVA
- PRP Power : 250 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (361,3 A)
- Type of container : 20′ HC
RHINO-360YC - 357 KVA
357 kVA GENERATOR
- ESP Power : 357 kVA
- PRP Power : 325 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (469,7 A)
- Type of container : 20′ HC
RHINO-415YC - 413 KVA
413 kVA GENERATOR
- ESP Power : 413 kVA
- PRP Power : 375 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (541,9 A)
- Type of container : 20′ HC
RHINO-440YC - 440 KVA
440 kVA GENERATOR
- ESP Power : 440 kVA
- PRP Power : 400 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (580 A)
- Type of container : 20′ HC
RHINO-500YC - 495 KVA
495 kVA GENERATOR
- ESP Power : 495 kVA
- PRP Power : 450 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (650,3 A)
- Type of container : 20′ HC
RHINO-550YC - 550 KVA
550 kVA GENERATOR
- ESP Power : 550 kVA
- PRP Power : 500 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (722,5 A)
- Type of container : 20′ HC
RHINO-620YC - 619 KVA
618 kVA GENERATOR
- ESP Power : 619 kVA
- PRP Power : 563 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (813,6 A)
- Type of container : 20′ HC
RHINO-690YC - 688 KVA
688 kVA GENERATOR
- ESP Power : 688 kVA
- PRP Power : 625 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (903,2 A)
- Type of container : 20′ HC
RHINO-825YC - 825 KVA
825 kVA GENERATOR
- ESP Power : 825 kVA
- PRP Power : 750 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (1083,8 A)
- Type of container : 20′ HC
RHINO-900YC - 888 KVA
888 kVA GENERATOR
- ESP Power : 888 kVA
- PRP Power : 810 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (1170,5 A)
- Type of container : 20′ HC
RHINO-1000YC - 990 KVA
990 kVA GENERATOR
- ESP Power : 990 kVA
- PRP Power : 900 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (1300,6 A)
- Type of container : 20′ HC
RHINO-1000YCE3 - 990 KVA
990 kVA GENERATOR
- ESP Power : 990 kVA
- PRP Power : 900 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (1300,6 A)
- Type of container : 20′ HC
RHINO-1100YC - 1100 KVA
1100 kVA GENERATOR
- ESP Power : 1100 kVA
- PRP Power : 1000 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (1445,1 A)
- Type of container : 20′ HC
RHINO-1100YCE3 - 1100 KVA
1100 kVA GENERATOR
- ESP Power : 1100 kVA
- PRP Power : 1000 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 6
- Autostart: optional
- Available in Three Phase (1445,1 A)
- Type of container : 20′ HC
RHINO-1250YC - 1250 KVA
1250 kVA GENERATOR
- ESP Power : 1250 kVA
- PRP Power : 1125 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 12
- Autostart: optional
- Available in Three Phase
- Type of container : 40′ HC
RHINO-1250YCE3 - 1250 KVA
1250 kVA GENERATOR
- ESP Power : 1250 kVA
- PRP Power : 1125 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 12
- Autostart: optional
- Available in Three Phase
- Type of container : 40′ HC
RHINO-1400YCE3 - 1375 KVA
1375 kVA GENERATOR
- ESP Power : 1375 kVA
- PRP Power : 1250 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 12
- Autostart: optional
- Available in Three Phase (1814 A)
- Type of container : 40′ HC
RHINO-1625YCE3 - 1625 KVA
1625 kVA GENERATOR
- ESP Power : 1625 kVA
- PRP Power : 1500 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 12
- Autostart: optional
- Available in Three Phase
- Type of container : 40′ HC
RHINO-1815YCE3 - 1650 KVA
1815 kVA GENERATOR
- ESP Power : 1815 kVA
- PRP Power : 1650 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 12
- Autostart: optional
- Available in Three Phase
- Type of container : 40′ HC
RHINO-2000YCE3 - 2000 KVA
2062 kVA GENERATOR
- ESP Power : 2000 kVA
- PRP Power : 1875 kVA
- Rotation speed : 1500 rpm
- Fuel tank capacity: N/A
- Number of cylinders : 12
- Autostart: optional
- Available in Three Phase
- Type of container : 40′ HC
ThE VARIOUS AREAS OF APPLICATION
• In an IPP (Interim Power Plant), ERP, mass distribution• Production and distribution of electrical energy
• Water treatment
• Health
• Telecommunications and information systems
• Transportation (railroad stations, highway networks, airports, etc.)
• The mining industry and all “heavy duty” applications.
THE EQUIPMENT OF THE RHINO SERIES
The RHINO solution is based on a normal standard container of 20 or 40 feet.
The internal surfaces are insulated for sound to reduce operating noise and to comply with sound emissions standards.
Two internal lighting circuits lit by LED projector, one 230V circuit fed by a grid or an electric generator, the other by a 24V circuit powered by battery motors.
They are equipped with ventilation made for the model of the electric generator. The rear doors of the container give access to them, as well as to the generator; in addition, the exterior side door accesses the control panel and the connections.
RHINO SOLUTIONS OPTIONS
The GELEC heavy line of electric generators can operate with aviation fuel. Large capacity 24h or 48h reservoirs or more can be included.
In order to limit noxious emissions, they can be equipped with exhaust systems, particle filtration systems and catalysts.
